L468, Dual HiPerFREDTM Epitaxial Diode in ISOPLUS i4-PACTM

Advanced Technical Information Dual HiPerFREDTM Epitaxial Diode in ISOPLUS i4-PACTM DSEE 55-24N1F VRRM = 2400 V IF(AV)M = 55 A trr = 220 ns 1 3 1.

datasheet Preview Page 1 from Datasheet4u.com

L468_IXYSCorporation.pdf

L468 Datasheet Preview — Preview of L468 PDF

Datasheet Details

Part number:

L468

Manufacturer:

IXYS Corporation

File Size:

45.31 KB

Description:

Dual HiPerFREDTM Epitaxial Diode in ISOPLUS i4-PACTM

Features

* 5
* HiPerFREDTM Epitaxial Diodes - fast and soft reverse recovery
* low switching losses - avalanche rated - low leakage current
* ISOPLUS i4-PACTM package - isolated back surface - low coupling capacity between pins and heatsink - enlarged creepage towards heatsink - enlar

Applications

* rectifiers - high frequency rectifiers, output rectifiers of switched mode power supplies - mains rectifiers with minimized emission of disturbances
* diodes in snubber networks
* high voltage diodes using the series connection in the component VF IR IRM trr RthJC IF = 40
