MMO110
Features
- Thyristor controller for AC (circuit W1C acc. to IEC) for mains frequency
- Isolation voltage 3000 V~
- Planar glass passivated chips
- Low forward voltage drop
- Lead suitable for PC board solering
I2t
TVJ = 45°C VR = 0 TVJ = 125°C VR = 0
Applications
- Switching and control of single and three phase AC circuits
- Light and temperature control
- Softstart AC motor controller
- Solid state switches
(di/dt)cr
TVJ = 125°C repetitive, IT = 50 A f = 50 Hz, t P = 200 µs VD = 2/3 VDRM IG = 0.45 A non repetitive, IT = ITAVM di G/dt = 0.45 A/µs TVJ = 125°C; VDR = 2/3 VDRM RGK = ∞; method 1 (linear voltage rise) TVJ = 125°C IT = ITAVM tp = 30 µs tp = 300 µs
500 1000 10 5 0.5 10 -40...+150 150 -40...+125
A/µs V/µs W W W V °C °C °C V~ V~
Advantages
- Easy to mount with two screws
- Space and weight savings
- Improved temperature and power cycling
- High power density
- Small and light weight
(dv/dt)cr PGM PGAVM VRGM TVJ TVJM Tstg VISOL Md Weight
50/60 Hz, RMS IISOL ≤ 1 m A...
