G1000NL450
G1000NL450 is Anode Shorted Gate Turn-Off Thyristor manufactured by IXYS.
WESTCODE
An IXYS pany
Date:- 16 Jun-04 Data Sheet Issue:- 1
Anode Shorted Gate Turn-Off Thyristor Type G1000NL450
Absolute Maximum Ratings
VDRM VRSM VRRM VDC-link
VOLTAGE RATINGS Repetitive peak off-state voltage, (note 1) Non-repetitive peak off-state voltage, (note 1) Repetitive peak reverse voltage Non-repetitive peak reverse voltage
MAXIMUM LIMITS 4500
UNITS V V V V
ITGQ Ls IT(AV)M IT(RMS) ITSM ITSM2 I2t di/dtcr VRGM Tj op Tstg
RATINGS Peak turn-off current, (note 2) Snubber loop inductance, ITM=ITGQ, (note 2) Mean on-state current, Tsink=55°C (note 3) Nominal RMS on-state current, 25°C (note 3) Peak non-repetitive surge current tp=10ms, (Note 4) Peak non-repetitive surge current tp=2ms, (Note 4) I2t capacity for fusing tp=10ms Critical rate of rise of on-state current, (note 5) Peak reverse gate voltage (note 6).
Operating temperature range Storage temperature range
Notes:1) VGK≤-2Volts. 2) Tj=125°C, VD=67%VDM, VDM<VDRM, di GQ/dt=25A/µs, CS=2µF....
