N3229QK060, N3229QK020 Datasheet - IXYS

N3229QK060 - Phase Control Thyristor

WESTCODE An IXYS Company Date:- 1 Aug, 2006 Data Sheet Issue:- 1 Provisional Data Wespack Phase Control Thyristor Types N3229QK020 to N3229QK060 Development Type No.: NX155QK020-060 Absolute Maximum Ratings VDRM VDSM VRRM VRSM VOLTAGE RATINGS Repetitive peak off-state voltage, (note 1) Non-repetitive peak off-state voltage, (note 1) Repetitive peak reverse voltage, (note 1) Non-repetitive peak reverse voltage, (note 1) MAXIMUM LIMITS 200-600 200-600 200-600 300-700 UNITS V V V V OTHER RAT.

N3229QK020-IXYS.pdf

This datasheet PDF includes multiple part numbers: N3229QK060, N3229QK020. Please refer to the document for exact specifications by model.
N3229QK060 Datasheet Preview Page 2 N3229QK060 Datasheet Preview Page 3

Datasheet Details

Part number:

N3229QK060, N3229QK020

Manufacturer:

IXYS

File Size:

388.40 KB

Description:

Phase control thyristor.

Note:

This datasheet PDF includes multiple part numbers: N3229QK060, N3229QK020.
Please refer to the document for exact specifications by model.
