W0428RF300 Rectifier Diode

WESTCODE An IXYS Company Date:- 16 Jun, 2006 Data Sheet Issue:- 1 Provisional Data Rectifier Diode Type W0428##250 to W0428##320 Development Type No.: WX171##250-320 Absolute Maximum Ratings VRRM VRSM VOLTAGE RATINGS Repetitive peak reverse voltage, (note 1) Non-repetitive peak reverse voltage, (note 1) MAXIMUM LIMITS 2500-3200 2600-3300 UNITS V V IF(AV)M IF(AV)M IF(AV)M IF(RMS) IF(RMS) IF(d.c.) IFSM IFSM2 I2t I2t Tj op Tstg OTHER RATINGS Maximum average forward current, Tcase=55°C, (not.

W0428RF300 Datasheet (298.92 KB)
