7912 - TO-220C Three Terminal Negative Voltage Regulator

Datasheet Summary

Features

Output current in excess of 1.5A.
Output voltage of -12V.
Internal thermal overload protection.
Output transition Safe-Area compensation.
Minimum Lot-to-Lot variations for robust device performance and reliable operation.

Inchange Semiconductor

📥 Download Datasheet

Datasheet Details

Part number	7912
Manufacturer	Inchange Semiconductor
File Size	152.22 KB
Description	TO-220C Three Terminal Negative Voltage Regulator
Datasheet	7912 Datasheet
Additional preview pages of the 7912 datasheet.

📁 Similar Datasheet

7912 - TO-252 Three Terminal Negative Voltage Regulator (INCHANGE)
7912CT - L7912CT (ETC)
7910 - Multi Melody (Seiko)
7914 - 4 mm SMD & Through-hole Sealed Key Switch (Bourns)
7915 - 3-Terminal Negative Regulator (Texas Instruments)
7915CV - Negative voltage regulators (STMicroelectronics)

Other Datasheets by Inchange Semiconductor

7915 - Three Terminal Negative Voltage Regulator

Full PDF Text Transcription

Click to expand full text

INCHANGE Semiconductor isc Product Specification isc Three Terminal Negative Voltage Regulator 7912 FEATURES ·Output current in excess of 1.5A ·Output voltage of -12V ·Internal thermal overload protection ·Output transition Safe-Area compensation ·Minimum Lot-to-Lot variations for robust device performance and reliable operation ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER RATING UNIT Vi DC input voltage -35 V Io Output current internally limited Ptot Power dissipation internally limited TOP Operating junction temperature 0~150 ℃ Tstg Storage temperature -55~150 ℃ THERMAL CHARACTERISTICS SYMBOL PARAMETER MAX UNIT Rth j-c Thermal Resistance, Junction to Case 3 ℃/W Rth j-a Thermal Resistance,Junction to Ambient 50 ℃/W isc website：www.iscsemi.
