TUA6024-2 - 2 Band TV Tuner Mixer-Oscillator-PLL with balanced IF-Amplifier

Infineon Technologies AG

The TUA6024-2 by Infineon Technologies AG is a 2 Band TV Tuner Mixer-Oscillator-PLL with balanced IF-Amplifier. Below is the official datasheet preview.

📥 Download Datasheet

TUA6024-2 2 Band TV Tuner Mixer-Oscillator-PLL with balanced IF-Amplifier by Infineon Technologies AG - Datasheet Preview — Official preview page of the **TUA6024-2** 2 Band TV Tuner Mixer-Oscillator-PLL with balanced IF-Amplifier datasheet (Infineon Technologies AG).

Datasheet Details

Part number	TUA6024-2
Manufacturer	Infineon Technologies AG
File Size	693.78 KB
Description	2 Band TV Tuner Mixer-Oscillator-PLL with balanced IF-Amplifier
Datasheet	TUA6024-2_InfineonTechnologiesAG.pdf
Additional preview pages of the TUA6024-2 datasheet.

TUA6024-2 Product details

Description

The TUA6024-2 is a 5 V mixer/oscilla- Package tor and synthesizer for TV and VCR tuners.

Features

Suitable for analog tuners and for digital CATV tuners Compatible with TUA6024-S and TUA6024-K in normal mode New features in extended mode Full ESD protection s s s Mixer/Oscillator s High impedance mixer input for LOW/MID band Low impedance mixer input for HIGH band 4 pin oscillator for LOW/MID band 4 pin oscillator for HIGH band PLL s s s s s s PLL with short lock-in time High voltage VCO tuning output Fast I 2C bus 3 NPN bandswitch buffers Internal LOW-MID/HIGH switch Lock-in flag Po.
