2ED21094S06J Datasheet, Driver, Infineon

2ED21094S06J Features

• Driver
• Unique Infineon Thin-Film-Silicon On Insulator (SOI)-technology
• Negative VS transient immunity of 100 V
• Floating channel designed for bootstrap operation <

PDF File Details

Part number:

2ED21094S06J

Manufacturer:

Infineon ↗

File Size:

1.03MB

Download:

📄 Datasheet

Description:

650v half bridge gate driver. The 2ED2109 (4) S06F (J) is a high voltage, high speed power MOSFET and IGBT driver with independent high and low side referenced out

2ED21094S06J Application

• Applications Driving IGBTs, enhancement mode N-Channel MOSFETs in various power electronic applications. Typical Infineon recommendations are as bel
