IAUA180N10S5N029
Features
- Opti MOS™ power MOSFET for automotive applications
- N-channel
- Enhancement mode
- Normal Level
- Extended qualification beyond AEC-Q101
- Enhanced electrical testing
- Robust design
- MSL3 up to 260°C peak reflow
- 175°C operating temperature
- Green product (Ro HS pliant)
- 100% Avalanche tested
Potential applications
General automotive applications.
Product validation
Qualified for automotive applications. Product validation according to AEC-Q101.
Product Summary
VDS RDS(on) ID (chip limited)
Type IAUA180N10S5N029
100 V 2.9 mΩ 180 A
Package PG-HSOF-5-4
PG-HSOF-5-4
1 1
1 2 3 4 5
Marking 5N10029
Data Sheet
Please read the Important Notice and Warnings at the end of this document
.infineon./mosfets
Rev. 1.1 2021-11-12
Opti MOS™ 5 Automotive Power MOSFET, 100 V
Table of Contents
Description
- -
- -
- -
- -
- -
- -
- -
- - ....
