IAUC45N04S6N070H Datasheet, Transistor, Infineon

IAUC45N04S6N070H Features

• Transistor
• OptiMOS™ - power MOSFET for automotive applications VDS RDS(on),max ID 40 V 7.0 mW 45 A PG-TDSON-8-57
• Half-Bridge - N-channel - Enhancement mode - Normal Level <

PDF File Details

Part number:

IAUC45N04S6N070H

Manufacturer:

Infineon ↗

File Size:

907.14kb

Download:

📄 Datasheet

Description:

Power transistor.

IAUC45N04S6N070H Application

• Applications VDS RDS(on),max ID 40 V 7.0 mW 45 A PG-TDSON-8-57
• Half-Bridge - N-channel - Enhancement mode - Normal Level
• AEC
