TD140N16SOF Datasheet - Infineon

TD140N16SOF - Phase Control Thyristor Module

Netz-Thyristor-Modul Phase Control Thyristor Module Technische Information / technical information TT140N16SOF Key Parameters VDRM / VRRM ITAVM ITSM VT0 rT RthJC Base plate Weight 1600 V 140 A (TC=85 °C) 34757000AA(TC=55°C) 1,0 V 1,6 mΩ 0,18 K/W 34 mm 165 g Merkmale Löt-Bond Technologie Industrie-Standard-Gehäuse Elektrisch isolierte Bodenplatte Typische Anwendungen Sanftanlasser Gleichrichter für Antriebsapplikationen Leistungssteller Gleichrichter

TD140N16SOF Features

* Solder-Bond Technology

* Industrial standard package

* Electrically insulated base plate Typical Applications

* Soft starter

* Rectifier for drives applications

* Power controllers

* Rectifiers for UPS

* Battery chargers

* Static switches content of customer DM

TD140N16SOF-Infineon.pdf

Preview of TD140N16SOF PDF
TD140N16SOF Datasheet Preview Page 2 TD140N16SOF Datasheet Preview Page 3

Datasheet Details

Part number:

TD140N16SOF

Manufacturer:

Infineon ↗

File Size:

365.48 KB

Description:

Phase control thyristor module.
