Bulletin PD-20239 rev. B 12/01
12TQ... 12TQ...S
SCHOTTKY RECTIFIER 15 Amp
IF(AV) = 15Amp VR = 35 to 45V
Major Ratings and Characteristics Characteristics
IF(AV) Rectangular waveform VRRM range IFSM @ tp = 5 µs sine VF TJ @ 15 Apk, TJ = 125°C range
Description/ Features Units
A The 12TQ... Schottky rectifier series has been optimized for very low forward voltage drop, with moderate leakage. The proprietary barrier technology allows for reliable operation up to 150° C junction temperature. Typical applications are in switching power supplies, converters, free-wheeling diodes, and reverse battery protection.
12TQ040S Datasheet
