HI-5049 Datasheet, Switches, Intersil Corporation

HI-5049 Features

• Switches very low power operation (1.5mW at 25oC). There are 7 devices in this switch series which are differentiated by type of switch action and value of rON (see Functional Description Table)

PDF File Details

Part number:

HI-5049

Manufacturer:

Intersil Corporation

File Size:

493.47kb

Download:

📄 Datasheet

Description:

Cmos analog switches. Table). The HI-504X and HI-505X series switches can directly replace IH-5040 series devices, and are functionally compatible with the

HI-5049 Application

• Applications
• High Frequency Switching
• Sample and Hold
• Digital Filters
• Operational Amplifier Gain Switching F
