ISL28246 - Op Amps

This page provides the datasheet information for the ISL28246, a member of the ISL28146 Op Amps family.

Datasheet Summary

Description

CONDITIONS MIN TYP VOS --Δ----V----O-----S--ΔTime Δ-----V----O----S-- ΔT Input Offset Voltage Long Term Input Offset Voltage

Features

  • Low Power 120µA typ supply current for both channels.
  • 225µV max offset voltage.
  • 30pA typ input bias current.
  • 300kHz gain-bandwidth product.
  • 100dB typ PSRR and CMRR.
  • Single supply operation down to 2.4V.
  • Input is capable of swinging above V+ and below V- (ground sensing).
  • Rail-to-rail input and output (RRIO).
  • Pb-free plus anneal available (RoHS compliant).

📥 Download Datasheet

Datasheet preview – ISL28246
