2EZ6.8D5 2W SILICON PLANAR ZENER DIODES

2EZ6.8D5 Description

R SEMICONDUCTOR 2EZ6.8D5 THRU 2EZ200D5 2W SILICON PLANAR ZENER DIODES .

2EZ6.8D5 Features

* Low leakage, low zener impedance at low current Maximum power dissipation of 2W is ideally suited for stabilized power supply, etc. High temperature soldering guaranteed:260°C/10 seconds at terminals MECHANICAL DATA DO-41 JF 0.107(2.7) 0.080(2.0) DIA 1.0(25.4) MIN 0.205(5.20) 0.161(4.10) Case: D

📥 Download Datasheet

Preview of 2EZ6.8D5 PDF
datasheet Preview Page 2

Datasheet Details

Part number
2EZ6.8D5
Manufacturer
JINAN JINGHENG
File Size
63.30 KB
Datasheet
2EZ6.8D5-JINANJINGHENG.pdf
Description
2W SILICON PLANAR ZENER DIODES
