1N4762, 1N4727 - 1W SILICON PLANAR ZENER DIODES

Name: 1N4762
SKU: 1N4762-911489

JINGHENG ELECTRONICS

The 1N4762 by JINGHENG ELECTRONICS is a 1W SILICON PLANAR ZENER DIODES. Below is the official datasheet preview.

Datasheet Details

Part number	1N4762, 1N4727
Manufacturer	JINGHENG ELECTRONICS
File Size	117.58 KB
Description	1W SILICON PLANAR ZENER DIODES
Datasheet	1N4727-JINGHENGELECTRONICS.pdf
Note	This datasheet PDF includes multiple part numbers: 1N4762, 1N4727. Please refer to the document for exact specifications by model.
Additional preview pages of the 1N4762 datasheet.

DO-41(GLASS) Silicon planar power zener diode For use in stabilizing and clipping circuits with high power rating. Standard Zener voltage tolerance is 10%. Add suffix "A" for 5% tolerance and suffix"B"for 2%tolerance. Other tolerance is available upon request. High temperature soldering guaranteed:260℃/10 seconds at terminals Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC JF 0.107(2.7) 0.080(2.0) DIA. 1.00(25.4) MIN. 0.205(5.20) 0.161(4.10).
