TX18D206VM0BPA Datasheet (KOE)

TX18D206VM0BPA, Display Module

FOR MESSRS : DATE: Jun.

6th ,2017 CUSTOMER’S ACCEPTANCE SPECIFICATIONS TX18D206VM0BPA Contents No.

ITEM 1 COVER 2 RECORD OF REVISION 3 GENERAL DATA 4 ABSOLUTE MAXIMUM RATINGS 5 ELECTRICAL CHARACTERISTICS 6 OPTICAL CHARACTERISTICS 7 BLOCK DIAGRAM 8 RELIABILITY TESTS 9 LCD INTERFACE 10 OUTLINE DIMENSIONS 11 TOUCH PANEL 12 APPEARANCE STANDARD 13 PRECAUTIONS 14 DESIGNATION OF LOT MARK SHEET No.

7B64PS 2701-TX18D206VM0BPA-5 7B64PS 2702-TX18D206VM0BPA-5 7B64PS 2703-TX18D206VM0BPA-

TX18D206VM0BPA Features

* This module is a 7.0” WVGA of 16:9 format amorphous silicon TFT. The pixel format is vertical stripe and sub pixels are arranged as R(red), G(green), B(blue) sequentially. This display is RoHS compliant, COG (chip on glass) technology and LED backlight are applied on this display. Part Name Module
