42BYGH3412-25 Stepper Motor

Fax Orders to 650-960-3875 Step Angle 1.8°±5% Insulation Resistant 500V DC 100MO Min Insulation Strength 50Hz 1Minute 500V Min Ambient Temperature -20ºC~+50ºC Temperature Rise 80ºC Max Shaft Radial Play 0.02mm Max Shaft End Play 0.1-0.3mm Stepper Motor HB Stepper Motors 42BYGH Series HB Stepper Motors Kysan # MFG# No.of Voltage Current Resistance Inductance Phase (V) (A) (Ohms) (mH) 1124015 1124016 1124017 1124018 1124019 1124020 1124021 1124022 1124023 1124024 1124025 1124026 1124027 11.

42BYGH3412-25 Datasheet (164.93 KB)

42BYGH3412-25 Datasheet Preview — Preview of 42BYGH3412-25 PDF

Datasheet Details

Part number:

42BYGH3412-25

Manufacturer:

KySan

File Size:

164.93 KB

Description:

Stepper motor.
