LM191E01-C4 - TFT LCD Module

Product Overview

LM191E01-C4 TFT LCD Module by LG - Datasheet Preview — Datasheet preview – LM191E01-C4

Datasheet Details

Part number	LM191E01-C4
Manufacturer	LG
File Size	584.24 KB
Description	TFT LCD Module
Datasheet	LM191E01-C4 Datasheet
Additional preview pages of the LM191E01-C4 datasheet.

Product details

Description

ABSOLUTE MAXIMUM RATINGS ELECTRICAL SPECIFICATIONS ELECTRICAL CHARACTREISTICS INTERFACE CONNECTIONS SIGNAL TIMING SPECIFICATIONS SIGNAL TIMING WAVEFORMS COLOR INPUT DATA REFERNECE www.DataSheet.net/ ITEM Page 1 2 3 4 5 6 6 9 12 13 14 15 16 20 23 24 24 24 25 25 25 26 POWER SEQUENCE OPTICAL SFECIFICATIONS MECHANICAL CHARACTERISTICS RELIABILITY INTERNATIONAL STANDARDS SAFETY EMC PACKING DESIGNATION OF LOT MARK PACKING FORM PRECAUTIONS Ver.0.4 Apr.07, 2003 2 / 27 Datasheet pdf - http://www.

Features

Active Screen Size Outline Dimension Pixel Pitch Pixel Format Color Depth Luminance, White Viewing Angle (CR>10) Power Consumption Weight Display Operating Mode Surface Treatment Ver. 0.4 19.0 inches(481.84mm) diagonal 404.2(H) x 330.0(V) x 22.3(D) mm(Typ. ) 0.294mm x 0.294mm 1280 horizontal By 1024 vertical Pixels RGB stripe arrangement 8-bits,16,777,216 colors 250 cd/m2 (Center 1 point (Typ. )) Viewing Angle Free [R/L 176(Typ. ), U/D 176(Typ. )] Total 22.76 Watt(Typ. ),(3.11 Watt@ VLCD,19.65Watt@2.
