LTS-2806SKG-P LED Display

Preliminary Spec. Correction Pin out Correction Pin 1 Position and Pin out Definition Change Reel Drawing By Eason Lin Eason Lin Eason Lin Eason Lin Date 02/09/2010 03/24/2010 09/15/2010 11/10/2010 Above data for PD and Customer tracking only - NPPR Received and Upload on System Eason Lin A Up.

LTS-2806SKG-P Features

* 0.28 inch (7.0 mm) DIGIT HEIGHT

* CONTINUOUS UNIFORM SEGMENTS

* LOW POWER REQUIREMENT

* EXCELLENT CHARACTERS APPEARANCE

* HIGH BRIGHTNESS & HIGH CONTRAST

* WIDE VIEWING ANGLE

* SOLID STATE RELIABILITY

* CATEGORIZED FOR LUMINOUS INTENSITY.

* LEAD-FREE PACKAGE(ACC

LTS-2806SKG-P-LITE-ON.pdf

LTS-2806SKG-P Datasheet Preview — This datasheet PDF includes multiple part numbers: LTS-2806SKG-P, LTS-2806SKG-P-LITE. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

LTS-2806SKG-P, LTS-2806SKG-P-LITE

Manufacturer:

LITE-ON

File Size:

417.77 KB

Description:

Led display.

Note:

This datasheet PDF includes multiple part numbers: LTS-2806SKG-P, LTS-2806SKG-P-LITE.
Please refer to the document for exact specifications by model.
