LTS-4801G-13
FEATURES
＊0.4 inch (10.0 mm ) DIGIT HEIGHT ＊EXCELLENT SEGMENT UNIFORMITY ＊LOW POWER REQUIREMENT ＊HIGH BRIGHTNESS AND HIGH CONTRAST ＊WIDE VIEWING ANGLE ＊SOLID STATE RELIABILITY ＊BINNED FOR LUMINOUS INTENSITY
DESCRIPTION
The LTS-4801G-13 is a 0.4 inch (10.0 mm) digit height single digit display. This device uses GREEN LED chips (Ga P epi on Ga P substrate). The display has gray face and white segments.
DEVICE
PART NO. GREEN
DESCRIPTION mon Anode Rt. Hand Decimal
PART NO.: LTS-4801G-13 BNS-OD-C131/A4
PAGE: 1 of 5
LITE-ON TECHNOLOGY CORPORATION
Property of LITE-ON Only
PACKAGE DIMENSIONS
NOTES: All dimensions are in millimeters. Tolerances are 0.25mm (0.01“) unless otherwise noted.
INTERNAL CIRCUIT DIAGRAM
PART NO.: LTS-4801G-13 BNS-OD-C131/A4
PAGE: 2 of 5
LITE-ON TECHNOLOGY CORPORATION
Property of LITE-ON Only
PIN CONNECTION
No
CONNECTION
Cathode G
Cathode F
3 mon Anode
Cathode E
Cathode D
Cathode DP
Cathode C
8 mon Anode
Cathode...
