S-LN7405HDT3WG
FEATURES
- Low thermal impedance.
- Exceptional on-resistance and maximum DC current capability
- We declare that the material of product pliance with
Ro HS requirements and Halogen Free.
- S-prefix for automotive and other applications requiring unique site and control change requirements; AEC-Q101 qualified and PPAP capable.
2. APPLICATIONS
- Load switch
1 2 3 4
DFN5060-8B
3. DEVICE MARKING AND RESISTOR VALUES
Device
Marking
Shipping
S-LN7405HDT3WG LN7405H 5000/Tape&Reel
4. MAXIMUM RATINGS
Parameter
Drain-to-Source Voltage
Gate-to-Source Voltage Continuous Drain Current(Note 1)
TA=25℃ TA=100℃
Pulsed Drain Current (Note 2)
Continuous Drain Current Pulsed Drain Current
TC=25℃ TC=100℃
Avalanche Current
Avalanche Energy(L=0.1m H) Power Dissipation
TA=25℃ TC=25℃
Operating Junction and Storage Temperature Range
Symbol Limits Unit
±20
24 m J
Tj/Tstg -55~+150...
