ISPXPLD5768MX, ISPXPLD5000MX - eXpanded Programmable Logic Device XPLD

Lattice Semiconductor

📥 Download Datasheet

ISPXPLD5768MX Datasheet Preview — This datasheet PDF includes multiple part numbers: ISPXPLD5768MX, ISPXPLD5000MX. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	ISPXPLD5768MX, ISPXPLD5000MX
Manufacturer	Lattice Semiconductor
File Size	860.30 KB
Description	eXpanded Programmable Logic Device XPLD
Datasheet	ISPXPLD5000MX_LatticeSemiconductor.pdf
Note	This datasheet PDF includes multiple part numbers: ISPXPLD5768MX, ISPXPLD5000MX. Please refer to the document for exact specifications by model.

ISPXPLD5768MX Product details

Features

Flexible Multi-Function Block (MFB) Architecture.
SuperWIDE™ logic (up to 136 inputs).
Arithmetic capability.
Single- or Dual-port SRAM.
FIFO.
Ternary CAM.
sysCLOCK™ PLL Timing Control.
Multiply and divide between 1 and 32.
Clock shifting capability.
External feedback capability.
sysIO™ Interfaces.
LVCMOS 1.8, 2.5, 3.3V.
Programmable impedance.
Hot-socketing.
Flexible bus-m.
