LTC4315 - 2-Wire Bus Buffer

Product Overview

Linear

Datasheet Details

Part number	LTC4315
Manufacturer	Linear
File Size	279.53 KB
Description	2-Wire Bus Buffer
Datasheet	LTC4315 Datasheet
Additional preview pages of the LTC4315 datasheet.

Product details

Description

The LTC4315 is a hot-swappable 2-wire bus buffer that provides bidirectional buffering, while maintaining a low offset voltage and high noise margin up to 0.3 VCC.

Features

n Bidirectional Buffer Increases Fanout n High Noise Margin with VIL = 0.3.
VCC n Compatible with Non-Compliant I2C Devices That Drive a High VOL n Selectable Rise Time Accelerator Current n Level Shift 1.5V, 1.8V, 2.5V, 3.3V and 5V Busses n Prevents SDA and SCL Corruption During Live Board Insertion and Removal from Backplane n Stuck Bus Disconnect and Recovery n Compatible with I2C, I2C Fast Mode and SMBus n ±4kV Human Body Model ESD Ruggedness n High Impedance SDA, SCL pins When Unpo.
