1N5643A Features
* Hermetically sealed
* Breakdown voltage range 6.8 - 200 volts
* Glass passivated junction
* Excellent clamping capability
* Low zener impedance
* 100% surge tested
* -55°C to +150°C
* Uni-polar ® 6 SILICON DIODE ARRAYS Min 31.8 Max 5.3
Datasheet Details
1N5643A, 1N5645A
219.29 KB
Silicon avalanche diodes.
This datasheet PDF includes multiple part numbers: 1N5643A, 1N5645A.
Please refer to the document for exact specifications by model.
