B1161UC4

SIDACtor Protection Thyristors

Image Manufacturer B2B MPN Description Distributor Stock Quantity Price Buy Now
part Littelfuse Inc B1161UC4LTP TVS DEV MIXED ADJUSTABLE MS-013 DigiKey 0 1500 units
$4.45

B1161UC4 Datasheet (1.10 MB)

Preview of B1161UC4 PDF Datasheet

Datasheet Details

Part number:

B1161UC4

Manufacturer:

Littelfuse ↗

File Size:

1.10 MB

Description:

Sidactor protection thyristors

B1161UC4 Features

* and Benefits t Low voltage overshoot t Low on-state voltage t Does not degrade with use t Fails short circuit when surged in excess of ratings t Dual-port protection t Gate trigger tracking device t Integrated diode for positive voltage surges Applicable Global Standards t TIA-968-A t TIA

B1161UC4 General Description

The Dual Port Negative Battrax® Series are programmable SIDACtor® devices designed to protect SLICs (Subscriber Line Interface Circuit) from damaging overvoltage transients. Dual port protection is provided by a programmable device that is referenced to a negative voltage souce while internal diodes.
