Description
Littelfuse DUR series Ultrafast Recovery Rectifier is designed to meet the general requirements of commercial applications by providing low Trr, high-temperature, lowleakage and low forward voltage drop products.
Features
- Ultra-fast switching.
- Low reverse leakage
current.
- High surge current
capability.
- Low forward voltage drop.
- Common Cathode
configuration in electrically isolated ITO-220AB package.
- Pb-free E3 means 2nd level interconnect is Pbfree and the terminal finish material is tin(Sn) (IPC/ JEDEC J-STD-609A.01)
Circuit Diagram
Base Common Cathode
1 Anode
2
3
Anode
Maximum Ratings.
