LCF121002A750TG Datasheet, Filter, Littelfuse

LCF121002A750TG Features

• Filter
• Effective for suppressing common mode noise and almost no effect for high speed differential data line
• Differential mode cut-off frequency up to 8.78GHz at -3dB

PDF File Details

Part number:

LCF121002A750TG

Manufacturer:

Littelfuse ↗

File Size:

4.74MB

Download:

📄 Datasheet

Description:

Common mode noise filter. Pin 1-3, 2-4 Pin 1-2(Short) to Pin 3-4(Short) Source 10mA DC Source Equipment Source Meter LCR Meter (3GHz) Pin1 Pin2 Pin3 Pin4

LCF121002A750TG Application

• Applications
• Mobile Phone and Tablet
• USB 3.1 Gen 1 & 2 (5 & 10Gbps) with Type C
• Display Port 1.2 (5.4Gbps)
• H
