SMBJ20, SMBJ5.0 Datasheet - Littelfuse

SMBJ20 TVS Diode

The SMBJ series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events. Bi-directional Agency Approvals Agency Agency File Number E230531 Maximum Ratings and Thermal Characteristics (TA=25OC unless other.

SMBJ20 Features

* Excellent clamping capability

* Low incremental surge resistance

* Typical IR less than 1μA when VBR min>12V

* For surface mounted applications to optimize board space

* Low profile package

* Typical failure mode is short from over-specified volta

SMBJ20, SMBJ5.0 Datasheet

This datasheet PDF includes multiple part numbers: SMBJ20, SMBJ5.0. Please refer to the document for exact specifications by model.
SMBJ20 Datasheet Preview Page 2 SMBJ20 Datasheet Preview Page 3

Datasheet Details

Part number:

SMBJ20, SMBJ5.0

Manufacturer:

Littelfuse ↗

File Size:

972.08 KB

Description:

Tvs diode.

This datasheet PDF includes multiple part numbers: SMBJ20, SMBJ5.0. Please refer to the document for exact specifications by model.
