SZ1SMB18AT3G
Description
The SZ1SMB series is designed to protect voltage sensitive ponents from high voltage, high energy transients.
Key Features
- Zener Transient Overvoltage Suppressors
- Working Peak Reverse Voltage Range − 5.0 V to 170 V for uni-directional, and 10 V to 78 V for bi-directional
- Standard Avalanche Breakdown Voltage Range −6.4 V to 209 V for unidirectional, 11.1 V to 95.80 V for bi-directional
- Peak Power − 600 W @ 1.0 ms
- ESD protection of data lines in accordance with IEC 61000-4-2 30kV(Air), 30kV (Contact)
- ESD Rating of Class 3 (> 16 kV) per Human Body Model
- Maximum Clamp Voltage @ Peak Pulse Current
- VBR @TJ = VBR@25°C x (1+αT x (TJ - 25)) (αT: Temperature Coefficient)
- Low Leakage < 5.0 µA Above 10 V
- Intended for UL 497B Type Protection
