AM50-0002 Datasheet, Amplifier, MA-COM

AM50-0002 Features

• Amplifier
• Low Noise Figure: 1.15 dB
• High Gain: 27 dB
• Low Power Consumption: 5V, 20 mA
• High Dynamic Range
• SOIC-8 Package Description M/A-COM’s AM5

PDF File Details

Part number:

AM50-0002

Manufacturer:

MA-COM

File Size:

125.60kb

Download:

📄 Datasheet

Description:

Low noise amplifier. M/A-COM’s AM50-0002 is a high performance GaAs MMIC low noise amplifier in a SOIC 8-lead surface mount plastic package. The AM50-0002

AM50-0002 Application

• Applications include receiver front ends in the Global Positioning System (GPS) market, as well as standard gain blocks, buffer amps, driver amps, a
