CD5292 Datasheet, Chips, MA-COM

CD5292 Features

• Chips
• All Junctions Completely Protected with Silicon Dioxide
• Constant Current over Wide Voltage Range
• Electrically Equivalent to 1N5283 - 1N5314 & 1N7048 - 1N70

PDF File Details

Part number:

CD5292

Manufacturer:

MA-COM

File Size:

628.90kb

Download:

📄 Datasheet

Description:

Current regulator diode chips. These 0.5 W zener diodes are electrically equivalent to the 1N5283 - 1N5314, 1N7048 - 1N7055 series diodes. They are compatible with
