MASW-011041-001SMB Datasheet, Switch, MA-COM

MASW-011041-001SMB Features

• Switch
• 200 W CW Incident Power @ +85°C
• Low Insertion Loss: <0.5 dB
• High Isolation: >40 dB
• Harmonics: <-70 dBc
• Operates from +V DC Bias Only

PDF File Details

Part number:

MASW-011041-001SMB

Manufacturer:

MA-COM

File Size:

674.83kb

Download:

📄 Datasheet

Description:

Sp3t 200w switch. The MASW-011041 is a high power PIN diode SP3T switch in a common anode configuration, operating from 50 MHz to 1 GHz. It features lo

MASW-011041-001SMB Application

• Applications that require higher CW and pulsed power operation. This device can operate with positive-only DC supplies, making it suitable for switc
