DB102
Features
- Halogen Free. "Green" Device (Note 1)
- Glass Passivated Chip Junction
- High Forward Surge Capability
- Epoxy Meets UL 94 V-0 Flammability Rating
- Lead Free Finish/Ro HS pliant (Note 2)("P" Suffix
Designates Ro HS pliant. See Ordering Information)
1 Amp Single Phase Bridge Rectifier 50 to 1000 Volts
Maximum Ratings @ 25°C (Unless Otherwise Specified)
Parameter
Peak Repetitive Reverse Voltage Working Peak Reverse Voltage
Value Symbol DB DB DB DB DB DB DB Unit
101 102 103 104 105 106 107
VRRM
VRWM 50 100 200 400 600 800 1000 V
DC Blocking Voltage VR
RMS Reverse Voltage
VRMS 35 70 140 280 420 560 700 V
Average Rectified
Forward Current
IF(AV)
@ TA=40°C
Non-Repetitive Peak
Surge Current @
8.3ms Half Sine Wave Non-Repetitive Peak
IFSM
Surge Current @
1ms Square Wave
Current Squared Time @1ms≤t≤8.3ms
I2t
A2s
Marking Code
Part Number DB101 DB102 DB103 DB104 DB105 DB106 DB107
Marking Code DB101 DB102 DB103 DB104 DB105 DB106...
