MBR2035FCT
Features
- High Surge Capacity
- High Current Capability and High Efficiency
- Halogen Free Available Upon Request By Adding Suffix "-HF"
- Lead Free Finish/Ro HS pliant(Note 1) ("P" Suffix Designates pliant. See Ordering Information)
- Epoxy Meets UL 94 V-0 Flammability Rating
- Moisture Sensitivity Level 1
Maximum Ratings
- Operatiang Junction Temperature Range: -55⁰C to +150⁰C
- Storage Temperature Range: -55⁰C to +150⁰C
- Typical Thermal Resistance : 4°C/W Junction to Case
MCC Part Number
Device Marking
Maximum Recurrent Peak Reverse
Voltage
Maximum RMS
Voltage
Maximum DC
Blocking Voltage
MBR2020FCT MBR2030FCT MBR2035FCT MBR2040FCT MBR2045FCT MBR2060FCT
MBR2080FCT MBR20100FCT
MBR2020FCT MBR2030FCT MBR2035FCT MBR2040FCT MBR2045FCT MBR2060FCT MBR2080FCT MBR20100FCT
20V 30V 35V 40V 45V 60V
80V 100V
14V 21V 24.5V 28V 31.5V 42V
56V 70V
20V 30V 35V 40V 45V 60V
80V 100V
Electrical Characteristics @ 25°C Unless Otherwise Specified
Average Forward Current IF(AV)
20A
TA=120⁰C...
