MBRD630CT, MBRD620CT - 6 Amp Schottky Barrier Rectifier

MCC

📥 Download Datasheet

MBRD630CT Datasheet Preview — This datasheet PDF includes multiple part numbers: MBRD630CT, MBRD620CT. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	MBRD630CT, MBRD620CT
Manufacturer	MCC
File Size	436.76 KB
Description	6 Amp Schottky Barrier Rectifier
Datasheet	MBRD620CT-MCC.pdf
Note	This datasheet PDF includes multiple part numbers: MBRD630CT, MBRD620CT. Please refer to the document for exact specifications by model.

MBRD630CT Product details

Features

Extremely Fast Switching.
Extremely Low Forward Drop.
Case Material: Molded Plastic. Classification Rating 94V-0 UL Flammability 6 Amp Schottky Barrier Rectifier 20 to 60 Volts Maximum Ratings.
Operating Temperature:- 65℃ to +150℃.
Storage Temperature: -65℃ to +175℃.
Maximum Thermal Resistance (Per Leg): 6℃/W Junction To Case 80℃/W Junction To Ambient MCC Part Number Device Marking Maximum Recurrent Peak Reverse Voltage Maximu m.
