B0512LS-1WR3 Datasheet, Converter, MORNSUN

B0512LS-1WR3 Features

• Converter
• Continuous short-circuit protection
• No-load input current as low as 5mA
• Operating temperature range: -40℃ ~ +105℃
• High efficiency up to 85%

PDF File Details

Part number:

B0512LS-1WR3

Manufacturer:

MORNSUN

File Size:

941.18kb

Download:

📄 Datasheet

Description:

Dc/dc converter. of reflected ripple current test method. Unit mA VDC Output Specifications Item Operating Conditions Voltage Accuracy Linear Re

B0512LS-1WR3 Application

• Applications where an isolated (two isolated) voltage is required in a distributed power supply system. They are suitable for: pure digital circuits
