Datasheet Details
- Part number
- M80002-4
- Manufacturer
- MOSDESIGN
- File Size
- 101.49 KB
- Datasheet
- M80002-4-MOSDESIGN.pdf
- Description
- 4-STRINGS XMAS LIGHT CONTROL
M80002-4 Description
MOSDESIGN SEMICONDUCTOR CORP.4 STRINGS XMAS LIGHT CONTROL IC GENERAL .
The M80002-4 is a CMOS ASIC designed for XMAS light controller use.
Power supply ra.
M80002-4 Features
* Power supply range : 2.5~4.5V
* Direct 4 SCR outputs
M80002-4 Applications
* XMAS light controller, any AC controlled device etc. . BLOCK DIAGRAM
XMAS LIGHT CONTROL
M80002-4
X OSCILLATOR
FREQ DIVIDER
CONTROL
KEY TG CONTROL
LOGIC
UNIT
LAMP DRIVER
S1 S2 S3 S4
* All specs and applications shown above subject to change without prior notice. ( , )
1/4
200
