MY9291, MY9291-MY Datasheet - MY-Semi

MY9291 12-Channel LED Driver

The MY9221, 12-channels (R/G/B x 4) c o n s t a n t current APDM (Adaptive Pulse Density M o d u l a t i o n ) LED driver, operates over a 3V ~ 5.5V input voltage range. The device provides 1 2 open-drain constant current sinking outputs that are rated to 1 7 V and delivers up to 60mA of high accura.

MY9291 Features

* a 1 0 M H z E M I r e d u c t i o n data clock input. MY9221 also offers a 2-wire serial interface to send the grayscale data, control command including 16/14/12/8-bit grayscale selection, grayscale clock frequency division selection, output polarity selection for high power LED driving, output Tr/T

MY9291-MY-Semi.pdf

This datasheet PDF includes multiple part numbers: MY9291, MY9291-MY. Please refer to the document for exact specifications by model.
MY9291 Datasheet Preview Page 2 MY9291 Datasheet Preview Page 3

Datasheet Details

Part number:

MY9291, MY9291-MY

Manufacturer:

MY-Semi

File Size:

830.09 KB

Description:

12-channel led driver.

Note:

This datasheet PDF includes multiple part numbers: MY9291, MY9291-MY.
Please refer to the document for exact specifications by model.
