ECJCV50J106M
http://..
CLASSIFICATION SUBJECT
SPECIFICATIONS
Multilayer Ceramic Chip Capacitor “12” (EIA 0805 ) VA Type Individual Specification
Ｎｏ．151S-ECJ-KBD38E PAGE
1 th of 1
DATE 23 Apr. 2003
1.Scope This specification applies to MATSUSHITA’S Multilayer Cer amic Chip C apacitor “ 0805 VA Type ” Temp. Char：X5R Rated voltage DC6.3V Nominal Cap.10µF. 2.Style and Dimensions Ｗ Ｌ２ Ｌ Ｌ１ ３．Operating Temperature Range Table ２ Temperature Characteristics X5R Operating Temp. Range. -55 to +85°C Ｔ Symbol Ｌ Ｗ Ｔ L1,L2 Table １ Dimensions(mm) 2.00±0.20 1.25±0.20 0.85±0.10 0.50±0.25
Class２
４．Individual Specification Table ３ Part Number ECJCV50J106M Rated Voltage D.C. 6.3V Temp. Char. X5R Nominal Capacitance 10 µF Cap. Tolerance M : ±20%
５．Explanation of Part Numbers C E C J mon Code
Temp. Char. Show in Table 4
０ J
1 0 6
Nominal Cap.
Cap. Tolerance Code Show in Table 3
Size Code Code Size C 0805 VA Type
Packaging Styles Packaging Code V φ180Reel Paper Taping 4000pcs
Rated Voltage Code...
