DS2045L Single-Piece 1M Nonvolatile SRAM

DS2045L Applications RAID Systems and Servers Industrial Controllers Gaming Router/Switches POS Terminals Data-Acquisition Systems Fire Alarms PLCs Pin Configuration appears at end of data sheet. PART DS2045L-100 TEMP RANGE -40°C to +85°C PIN-PACKAGE 256 Ball 27mm2 BGA Module w w w P4.0 P3.

Rev 1; 4/05 w The DS2045L is a 1Mb reflowable nonvolatile (NV) SRAM, which consists of a static RAM (SRAM), an NV controller, and an internal rechargeable manganese lithium (ML) battery. These components are encased in a surface-mount module with a 256-ball BGA footprint. Whenever VCC is applied to the module, it recharges the ML battery, powers the SRAM from the external power source, and allows the contents of the SRAM to be modified. When VCC is powered down or out-of-tolerance, the control.

DS2045L Features

* Single-Piece, Reflowable, BGA Package Footprint

* Internal ML Battery and Charger

* Unconditionally Write-Protects SRAM when VCC is Out-of-Tolerance

* Automatically Switches to Battery Supply when VCC Power Failures Occur

* Internal Power-Supply Monitor Dete
