MAX8804Z, MAX8804Y - USB/AC Adapter Chargers

MAX8804Z Description

www.DataSheet4U.com 19-0785; Rev 0; 4/07 High-Voltage, Dual-Input, USB/AC Adapter Chargers in 2mm x 3mm TDFN General .
The MAX8804Y/MAX8804Z intelligent, dual-input, stand-alone, constant-current, constant-voltage (CCCV), thermally regulated linear chargers are designe.

MAX8804Z Features

* include an active-low battery charging-status indicator (CHG), an active-low power-OK indicator (POK), and an active-low USB input detection output (USBPWR). The MAX8804Y/MAX8804Z accept a 4.15V to 30V DC source voltage or a 4.15V to 16V USB input voltage, but disable charging when either input volt

MAX8804Z Applications

* Cell Phones/Smartphones Digital Cameras Portable Media Players MP3 Players Other Handheld Devices AC ADAPTER DC 1μ F GND CHG USB PORT MAX8804Y MAX8804Z POK USBPWR BAT USB 1μ F ENABLE/DISABLE AND PROGRAMMING SET 2.2μF Li+ Pin Configuration appears at end of data sheet. _____________________
