MAX9994 - 1700MHz to 2200MHz Downconversion Mixer

Datasheet Summary

Description

The MAX9994 high-linearity downconversion mixer provides 8.3dB gain, +26.2dBm IIP3, and 9.7dB NF for 1700MHz to 2200MHz UMTS/WCDMA, DCS, and PCS base-station receiver applications.

Features

  • o 1700MHz to 2200MHz RF Frequency Range o 1400MHz to 2000MHz LO Frequency Range (MAX9994) o 1900MHz to 2400MHz LO Frequency Range (MAX9996) o 40MHz to 350MHz IF Frequency Range o 8.3dB Conversion Gain o +26.2dBm Input IP3 o +12.6dBm Input 1dB Compression Point o 9.7dB Noise Figure o 67dBc 2RF - 2LO Spurious Rejection at PRF = -10dBm o Integrated LO Buffer o Integrated RF and LO Baluns for Single-Ended Inputs o Low -3dBm to +3dBm LO Drive o Built-In SPDT LO Switch with 45dB LO1 to LO2 Isolation a.

📥 Download Datasheet

Datasheet preview – MAX9994

Datasheet Details

Part number MAX9994
Manufacturer Maxim Integrated Products
File Size 346.13 KB
Description 1700MHz to 2200MHz Downconversion Mixer
Datasheet download datasheet MAX9994 Datasheet
Additional preview pages of the MAX9994 datasheet.

📁 Similar Datasheet

  • MAX9993 - High-Linearity 1700MHz to 2200MHz Down- Conversion Mixer with LO Buffer/Switch (Maxim)
  • MAX9995 - Dual / SiGe / High-Linearity / 1700MHz to 2200MHz Downconversion Mixer (Maxim)
  • MAX990 - Micropower / Low-Voltage / SOT23 / Rail-to-Rail I/O Comparators (Maxim)
  • MAX991 - High-Speed / Micropower / Low-Voltage / SOT23 / Rail-to-Rail I/O Comparators (Maxim)
  • MAX992 - High-Speed / Micropower / Low-Voltage / SOT23 / Rail-to-Rail I/O Comparators (Maxim)
  • MAX993 - Micropower / Low-Voltage / SOT23 / Rail-to-Rail I/O Comparators (Maxim)
  • MAX9937 - Current-Sense Amplifier (Maxim Integrated)
  • MAX994 - Micropower / Low-Voltage / SOT23 / Rail-to-Rail I/O Comparators (Maxim)
  • MAX995 - High-Speed / Micropower / Low-Voltage / SOT23 / Rail-to-Rail I/O Comparators (Maxim)
  • MAX996 - High-Speed / Micropower / Low-Voltage / SOT23 / Rail-to-Rail I/O Comparators (Maxim)
Other Datasheets by Maxim Integrated Products
  • MAX999 - Beyond-the-Rails Comparators
  • MAX9990 - (MAX9989 / MAX9990) +14dBm to +20dBm LO Buffers
  • MAX9996 - 1700MHz to 2200MHz Downconversion Mixer
  • MAX9910 - (MAX9910 - MAX9913) Rail-to-Rail I/O Op Amps
  • MAX9911 - (MAX9910 - MAX9913) Rail-to-Rail I/O Op Amps
  • MAX9912 - (MAX9910 - MAX9913) Rail-to-Rail I/O Op Amps
  • MAX9913 - (MAX9910 - MAX9913) Rail-to-Rail I/O Op Amps
  • MAX9914 - (MAX9914 - MAX9917) Rail-to-Rail I/O Op Amps

Full PDF Text Transcription

Click to expand full text
19-3435; Rev 0; 10/04 KIT ATION EVALU E L B A IL AVA www.DataSheet4U.com SiGe High-Linearity, 1700MHz to 2200MHz Downconversion Mixer with LO Buffer/Switch General Description The MAX9994 high-linearity downconversion mixer provides 8.3dB gain, +26.2dBm IIP3, and 9.7dB NF for 1700MHz to 2200MHz UMTS/WCDMA, DCS, and PCS base-station receiver applications. With a 1400MHz to 2000MHz LO frequency range, this particular mixer is ideal for low-side LO injection receiver architectures. High-side LO injection is supported by the MAX9996*, which is pin-for-pin and functionally compatible with the MAX9994. In addition to offering excellent linearity and noise performance, the MAX9994 also yields a high level of component integration.
