GS1J
FEATURES
- Peak Surge Overload Rating: 30A
- Low profile package
- Low forward voltage drop
- Glass passivated Die construction
- Terminals: Solder plated, solderable per MIL-STD-750
- UL Flammability Classification 94V-O
ELECTRICAL CHARACTERISTICS
Parameter
Symbol GS1A GS1B GS1D GS1G GS1J
Maximum Recurrent Peak Reverse Voltage Maximum RMS Voltage Maximum DC Blocking Voltage
VRRM VRMS VDC
100 200 400 600
140 280 420
100 200 400 600
Maximum Average Forward Rectified Current at TL=100°C
I(AV)
Peak Forward Surge Current,
8.3ms single half-sine-wave superimposed
IFSM
30 on rated load (JEDEC method)
Maximum Forward Voltage at 1.0A
Maximum Reverse Current at Rated DC Blocking Voltage
TA=25°C TA=125°C
5.0 100
Typical Junction Capacitance
Typical Thermal Resistance- Junction to Ambient
RθJA
Maximum Reverse Recovery Time Operating Junction Temperature Range Storage Temperature Range
TRR TJ TSTG
2.5 -65 to +150 -65 to...
