SY10E101, SY100E101 Datasheet - Micrel Semiconductor

SY10E101 QUAD 4-INPUT OR/NOR GATE

SY10E101 Features

* s 500ps max. propagation delay s Extended 100E VEE range of

* 4.2V to

* 5.5V s True and complementary outputs s Fully compatible with industry standard 10KH, 100K I/O levels s Internal 75KΩ input pulldown resistors s Fully compatible with Motorola MC10E/100E101 s Available in 28-pin PL

SY100E101_MicrelSemiconductor.pdf

SY10E101 Datasheet Preview — This datasheet PDF includes multiple part numbers: SY10E101, SY100E101. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

SY10E101, SY100E101

Manufacturer:

Micrel Semiconductor

File Size:

59.96 KB

Description:

Quad 4-input or/nor gate.

Note:

This datasheet PDF includes multiple part numbers: SY10E101, SY100E101.
Please refer to the document for exact specifications by model.
