DSC6011, DSC6001 - Ultra-Low Power MEMS Oscillator

Microchip

Datasheet Details

Part number	DSC6011, DSC6001
Manufacturer	Microchip
File Size	568.19 KB
Description	Ultra-Low Power MEMS Oscillator
Datasheet	DSC6001-Microchip.pdf
Note	This datasheet PDF includes multiple part numbers: DSC6011, DSC6001. Please refer to the document for exact specifications by model.

Wide Frequency Range: 2 kHz to 80 MHz.
Ultra-Low Power Consumption: 1.3 mA/12 A (Active/Stdby).
Ultra-Small Footprints - 1.6 mm  1.2 mm - 2.0 mm  1.6 mm - 2.5 mm  2.0 mm - 3.2 mm  2.5 mm.
Frequency Select Input Supports 2 Predefined Frequencies.
High Stability: ±25, ±50 ppm.
Wide Temperature Range - Industrial:.
40°C to 85°C - Ext. Commercial:.
20° to 70°C.
Excellent Shock & Vibration Immunity - Qualified to MIL.
