MIC4126 Datasheet, Drivers, Microchip

MIC4126 Features

• Drivers
• Dual 1.5A-Peak Drivers
• 4.5V to 20V Operating Range
• Exposed Backside Pad Packaging Reduces Heat - ePAD SOIC-8L (JA = 58°C/W) - ePAD MSOP-8L (JA = 60°C/W)

PDF File Details

Part number:

MIC4126

Manufacturer:

Microchip ↗

File Size:

1.26MB

Download:

📄 Datasheet

Description:

Dual 1.5a-peak low-side mosfet drivers. The MIC4126, MIC4127, and MIC4128 family are highly-reliable dual 1.5A low-side MOSFET drivers fabricated on Microchip’s BiCMOS/DMOS

MIC4126 Application

• Applications
• DC/DC Converters
• Motor Drivers - Clock Line Driver General Description The MIC4126, MIC4127, and MIC4128 family ar
