PIC16F15214
Features
- C piler Optimized RISC Architecture
- Operating Speed:
- DC
- 32 MHz clock input
- 125 ns minimum instruction time
- 16-Level Deep Hardware Stack
- Low-Current Power-on Reset (POR)
- Configurable Power-up Timer (PWRT)
- Brown-out Reset (BOR)
- Watchdog Timer (WDT)
Memory
- Up to 28 KB of Program Flash Memory
- Up to 2 KB of Data SRAM Memory
- Memory Access Partition (MAP): The Program Flash Memory Can Be Partitioned into:
- Application Block
- Boot Block
- Storage Area Flash (SAF) Block
- Programmable Code Protection and Write Protection
- Device Information Area (DIA) Stores:
- Fixed Voltage Reference (FVR) measurement data
- Microchip Unique Identifier
- Device Characteristics Area (DCI) Stores:
© 2020-2022 Microchip Technology Inc. and its subsidiaries
Data Sheet
DS40002195E-page 2
PIC16F15213/14/23/24/43/44
- Program/erase row sizes
- Pin count details
- Direct, Indirect and Relative Addressing Modes
Operating Characteristics
- Operating Voltage Range:
- 1.8V to...
