SAME53J20, SAME53N20 - 32-bit ARM Cortex-M4F MCUs

Microchip

📥 Download Datasheet

SAME53J20 Datasheet Preview — This datasheet PDF includes multiple part numbers: SAME53J20, SAME53N20. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	SAME53J20, SAME53N20
Manufacturer	Microchip
File Size	17.66 MB
Description	32-bit ARM Cortex-M4F MCUs
Datasheet	SAME53N20-Microchip.pdf
Note	This datasheet PDF includes multiple part numbers: SAME53J20, SAME53N20. Please refer to the document for exact specifications by model.

SAME53J20 Product details

Features

Operating Conditions:.
1.71V to 3.63V, -40°C to +125°C, DC to 100 MHz.
1.71V to 3.63V, -40°C to +105°C, DC to 120 MHz.
1.71V to 3.63V, -40°C to +85°C, DC to 120 MHz Core: 120 MHz Arm Cortex-M4.
403 CoreMark® at 120 MHz.
4 KB combined instruction cache and data cache.
8-Zone Memory Protection Unit (MPU).
Thumb®-2 instruction set.
Embedded Trace Module (ETM) with instruction trace stream.
Core Sight Embedded Trace Buf.
