MT29F1G16ABB - (MT29F1GxxABB) 1Gb NAND Flash Memory

Description

.

.

Features

  • 1Gb NAND Flash Memory MT29F1GxxABB For the latest data sheet, refer to Micron's Web site: www. micron. com/datasheets Features.
  • Organization.
  • Page size x8: 2,112 bytes (2,048 + 64 bytes).
  • Page size x16: 1,056 words (1,024 + 32 words).
  • Block size: 64 pages (128K + 4K bytes).
  • Device size: 1Gb: 1,024 blocks.
  • READ performance.
  • Random READ: 25µs (MAX).
  • Sequential READ: 50ns (MIN).
  • WRITE performance.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MT29F1GxxABB 1Gb NAND Flash Memory Micron
MT29F128G08AJAAA NAND Flash Memory Micron
MT29F128G08AKAAA NAND Flash Memory Micron
MT29F128G08AKCAB NAND Flash Memory Micron
MT29F128G08AMAAA NAND Flash Memory Micron

Other Datasheets by Micron Technology

Part Number Description
MT29F1G16ABBDAH4 NAND Flash Memory
MT29F1G16ABBDAHC NAND Flash Memory
MT29F1G16ABBEAH4 NAND Flash Memory
MT29F1G16ABBEAH4-IT NAND Flash Memory
MT29F1G16ABBEAHC NAND Flash Memory

Full PDF Text Transcription

Click to expand full text
www.DataSheet4U.com Micron Confidential and Proprietary Advance‡ 1Gb: x8, x16 NAND Flash Memory Features 1Gb NAND Flash Memory MT29F1GxxABB For the latest data sheet, refer to Micron's Web site: www.micron.com/datasheets Features • Organization • Page size x8: 2,112 bytes (2,048 + 64 bytes) • Page size x16: 1,056 words (1,024 + 32 words) • Block size: 64 pages (128K + 4K bytes) • Device size: 1Gb: 1,024 blocks • READ performance • Random READ: 25µs (MAX) • Sequential READ: 50ns (MIN) • WRITE performance • PROGRAM PAGE: 300µs (TYP) • BLOCK ERASE: 2.0ms (TYP) • Endurance: 100,000 PROGRAM/ERASE cycles • Data retention: 10 years • The first block (block address 00h) is guaranteed to be valid without ECC (up to 1,000 PROGRAM/ERASE cycles). • VCC: 1.65V–1.
